View Issue Details
| ID | Project | Category | View Status | Date Submitted | Last Update |
|---|---|---|---|---|---|
| 0017705 | Scribus | User Interface | public | 2025-12-07 20:47 | 2025-12-07 21:36 |
| Reporter | cbradney | Assigned To | nitramr | ||
| Priority | normal | Severity | minor | Reproducibility | always |
| Status | assigned | Resolution | open | ||
| Product Version | 1.7.1.svn | ||||
| Summary | 0017705: Dark Color Schema unusable | ||||
| Description | When the Dark Color Scheme is selected in kde a lot of menus in scribus become unusable. Mostly the third submenu is unreadable. | ||||
| Steps To Reproduce | Just open Insert->Forms->Standardforms (Maybe english translation wrong, I have a german setup). The menupoints exist but only the icon in front of the text is visible. | ||||
| Tags | No tags attached. | ||||
| Patch | No | ||||
|
|
From 0017704 @nitramr: This patch should fix the icon color refresh after the UI theme has changed. It fixes the following places: - Tool Toolbar -> Shape menu - View Toolbar -> Color vision dropdown / image resolution dropdown - PP Line Section -> Arrow selector - Page Palette -> Page Layout selector colorfix.patch (14,366 bytes)
diff --git a/scribus/ui/autoformbuttongroup.cpp b/scribus/ui/autoformbuttongroup.cpp
index 9cf90054d..03eaba138 100644
--- a/scribus/ui/autoformbuttongroup.cpp
+++ b/scribus/ui/autoformbuttongroup.cpp
@@ -759,9 +759,10 @@ QPixmap AutoformButtonGroup::getIconPixmap(int nr, int pixmapSize)
// painter->end();
// delete painter;
+
QPainter *painter = new QPainter(&Ico);
- painter->setBrush( palette().color(QPalette::WindowText) );
- painter->setPen( QPen(palette().color(QPalette::Midlight), 1.0, Qt::SolidLine, Qt::FlatCap, Qt::MiterJoin) );
+ painter->setBrush( ScQApp->palette().color(QPalette::WindowText) );
+ painter->setPen( QPen(ScQApp->palette().color(QPalette::Midlight), 1.0, Qt::SolidLine, Qt::FlatCap, Qt::MiterJoin) );
painter->translate(2.0, 2.0);
painter->drawPath( Path.toQPainterPath(true) );
painter->end();
diff --git a/scribus/ui/linemarkerselector.cpp b/scribus/ui/linemarkerselector.cpp
index f0791531a..ea400de06 100644
--- a/scribus/ui/linemarkerselector.cpp
+++ b/scribus/ui/linemarkerselector.cpp
@@ -1,5 +1,6 @@
#include "linemarkerselector.h"
#include "ui/delegates/sclistitemdelegate.h"
+#include "scribusapp.h"
/* ********************************************************************************* *
*
@@ -24,6 +25,8 @@ LineMarkerSelector::LineMarkerSelector(QWidget *parent) :
emit scaleChanged(scale());
});
+ connect(ScQApp, SIGNAL(iconSetChanged()), this, SLOT(redrawIcons()));
+
}
/* ********************************************************************************* *
@@ -37,6 +40,7 @@ void LineMarkerSelector::rebuildList(const QList<ArrowDesc> *arrowStyles)
// ArrowStyles defined in: void PrefsManager::initArrowStyles()
int index = marker() == -1 ? 0 : marker();
+ m_arrowStyles = arrowStyles;
listMarker->clear();
qreal m_devicePixelRatio = qApp->devicePixelRatio();
@@ -68,6 +72,14 @@ void LineMarkerSelector::addItem(QPixmap pixmap, const QString &label, int id)
listMarker->addItem(item);
}
+void LineMarkerSelector::redrawIcons()
+{
+ if (m_arrowStyles->empty())
+ return;
+
+ rebuildList(m_arrowStyles);
+}
+
/* ********************************************************************************* *
*
* Properties
@@ -131,7 +143,7 @@ void LineMarkerSelector::setScaleSuffix(const QString suffix)
QPixmap LineMarkerSelector::renderPixmap(FPointArray path, int width, int height, int scale)
{
- const QPalette& pal = this->palette();
+ const QPalette& pal = ScQApp->palette();
QColor textColor = pal.color(QPalette::Active, QPalette::Text);
int offsetX = 0, offsetY = 0, lineStart = 0, lineEnd = 0;
diff --git a/scribus/ui/linemarkerselector.h b/scribus/ui/linemarkerselector.h
index 3bceae21c..415f55a67 100644
--- a/scribus/ui/linemarkerselector.h
+++ b/scribus/ui/linemarkerselector.h
@@ -29,11 +29,15 @@ public:
private:
ArrowDirection m_arrowDirection { ArrowDirection::StartArrow };
int arrow = 23;
+ const QList<ArrowDesc> *m_arrowStyles;
QPixmap renderPixmap(FPointArray path, int width, int height, int scale);
void addItem(QPixmap pixmap, const QString &label, int id);
+private slots:
+ void redrawIcons();
+
signals:
void scaleChanged(double);
void markerChanged(int);
diff --git a/scribus/ui/viewtoolbar.cpp b/scribus/ui/viewtoolbar.cpp
index 5434e2fcd..3bd63bc3e 100644
--- a/scribus/ui/viewtoolbar.cpp
+++ b/scribus/ui/viewtoolbar.cpp
@@ -110,6 +110,7 @@ void ViewToolBar::languageChange()
visualMenu->addAction(im.loadIcon("color-vision-colorblind", iconSize()), CommonStrings::trVisionFullColorBlind);
visualMenu->setToolTip( tr("Select the visual appearance of the display. You can choose between normal and several color blindness forms."));
visualMenu->setStatusTip( tr("Select display visual appearance"));
+ visualMenu->setCurrentIndex(visualMenu->currentIndex());
QSignalBlocker sigImageRes(previewQualitySwitcher);
previewQualitySwitcher->clear();
@@ -118,5 +119,6 @@ void ViewToolBar::languageChange()
previewQualitySwitcher->addAction(im.loadIcon("image-resolution-low", iconSize()), tr("Low"));
previewQualitySwitcher->setToolTip( tr("Select the image preview quality"));
previewQualitySwitcher->setStatusTip( tr("Select image preview quality"));
+ previewQualitySwitcher->setCurrentIndex(previewQualitySwitcher->currentIndex());
}
diff --git a/scribus/ui/widgets/dropdown_button.cpp b/scribus/ui/widgets/dropdown_button.cpp
index 4d1a8e5fe..de4fecdb8 100644
--- a/scribus/ui/widgets/dropdown_button.cpp
+++ b/scribus/ui/widgets/dropdown_button.cpp
@@ -1,17 +1,24 @@
#include <QMenu>
#include "dropdown_button.h"
+#include "scribusapp.h"
DropdownButton::DropdownButton(QWidget *parent) : QToolButton(parent)
{
setPopupMode(QToolButton::InstantPopup);
+ connect(ScQApp, SIGNAL(iconSetChanged()), this, SLOT(iconSetChange()));
}
void DropdownButton::setCurrentIndex(int index)
{
m_index = index;
- if (menu())
- indexChanged(menu()->actions().at(qBound(0, index, menu()->actions().size())));
+ if (!menu())
+ return;
+
+ if (menu()->actions().empty())
+ return;
+
+ indexChanged(menu()->actions().at(qBound(0, index, menu()->actions().size())));
}
void DropdownButton::setMenu(QMenu *menu)
@@ -49,3 +56,10 @@ void DropdownButton::indexChanged(QAction *action)
emit activated(m_index);
}
}
+
+void DropdownButton::iconSetChange()
+{
+ this->blockSignals(true);
+ setCurrentIndex(m_index);
+ this->blockSignals(false);
+}
diff --git a/scribus/ui/widgets/dropdown_button.h b/scribus/ui/widgets/dropdown_button.h
index f4cad2b11..6e60efdc4 100644
--- a/scribus/ui/widgets/dropdown_button.h
+++ b/scribus/ui/widgets/dropdown_button.h
@@ -21,6 +21,7 @@ private:
private slots:
void indexChanged(QAction *action);
+ void iconSetChange();
signals:
void currentIndexChanged(int index);
diff --git a/scribus/ui/widgets/pagelayout.cpp b/scribus/ui/widgets/pagelayout.cpp
index 24aafeab6..a653d11b4 100644
--- a/scribus/ui/widgets/pagelayout.cpp
+++ b/scribus/ui/widgets/pagelayout.cpp
@@ -18,6 +18,7 @@ for which a new license (GPL+exception) is in place.
#include "iconmanager.h"
#include "scribusapp.h"
#include "ui/widgets/form_widget.h"
+#include "ui/widgets/dropdown_button.h"
PageLayouts::PageLayouts(QWidget* parent) : QWidget( parent )
{
@@ -37,11 +38,8 @@ PageLayouts::PageLayouts(QWidget* parent) : QWidget( parent )
QFont layFont(this->font());
layFont.setPointSize(8);
- menuScheme = new QMenu();
-
- buttonScheme = new QToolButton(this);
+ buttonScheme = new DropdownButton(this);
buttonScheme->setPopupMode(QToolButton::InstantPopup);
- buttonScheme->setMenu(menuScheme);
labelScheme = new FormWidget();
labelScheme->setFont(layFont);
@@ -49,11 +47,8 @@ PageLayouts::PageLayouts(QWidget* parent) : QWidget( parent )
labelScheme->setLabelVisibility(!m_hideLabels);
layoutGroupLayout->addWidget( labelScheme );
- menuFirstPage = new QMenu();
-
- buttonFirstPage = new QToolButton(this);
+ buttonFirstPage = new DropdownButton(this);
buttonFirstPage->setPopupMode(QToolButton::InstantPopup);
- buttonFirstPage->setMenu(menuFirstPage);
labelPages = new FormWidget();
labelPages->setFont(layFont);
@@ -64,8 +59,9 @@ PageLayouts::PageLayouts(QWidget* parent) : QWidget( parent )
languageChange();
connect(ScQApp, SIGNAL(labelVisibilityChanged(bool)), this, SLOT(toggleLabelVisibility(bool)));
- connect(menuScheme, &QMenu::triggered, this, &PageLayouts::changeScheme);
- connect(menuFirstPage, &QMenu::triggered, this, &PageLayouts::changeFirstPage);
+ connect(ScQApp, SIGNAL(iconSetChanged()), this, SLOT(languageChange()));
+ connect(buttonScheme, &DropdownButton::activated, this, &PageLayouts::changeScheme, Qt::UniqueConnection);
+ connect(buttonFirstPage, &DropdownButton::activated, this, &PageLayouts::changeFirstPage, Qt::UniqueConnection);
}
void PageLayouts::updateSchemeSelector(QList<PageSet> pageSets, int pagePositioning)
@@ -79,22 +75,22 @@ void PageLayouts::updateSchemeSelector(QList<PageSet> pageSets, int pagePosition
void PageLayouts::setFirstPage(int nr)
{
- if (menuFirstPage->actions().isEmpty())
+ if (buttonFirstPage->actions().isEmpty())
return;
- m_firstPage = qBound(0, nr, static_cast<int>(menuFirstPage->actions().count()));
- buttonFirstPage->setIcon(menuFirstPage->actions().at(m_firstPage)->icon());
+ m_firstPage = qBound(0, nr, static_cast<int>(buttonFirstPage->actions().count()));
+ buttonFirstPage->setCurrentIndex(m_firstPage);
}
void PageLayouts::setScheme(int nr)
{
- if (menuScheme->actions().isEmpty())
+ if (buttonScheme->actions().isEmpty())
return;
- m_scheme = qBound(0, nr, static_cast<int>(menuScheme->actions().count()));
- buttonScheme->setIcon(menuScheme->actions().at(m_scheme)->icon());
+ m_scheme = qBound(0, nr, static_cast<int>(buttonScheme->actions().count()));
reloadFirstPage(m_scheme);
+ buttonScheme->setCurrentIndex(m_scheme);
}
@@ -106,9 +102,7 @@ void PageLayouts::setHideLabelsPermanently(bool hide)
void PageLayouts::reloadScheme()
{
- disconnect(menuScheme, &QMenu::triggered, this, &PageLayouts::changeScheme);
-
- menuScheme->clear();
+ buttonScheme->clear();
for (int pg = 0; pg < m_pageSets.count(); ++pg)
{
@@ -118,25 +112,21 @@ void PageLayouts::reloadScheme()
QString psname = CommonStrings::translatePageSetString(m_pageSets[pg].Name);
if (pg == 0)
- menuScheme->addAction(IconManager::instance().loadIcon("page-simple"), psname)->setData(QVariant(pg));
+ buttonScheme->addAction(IconManager::instance().loadIcon("page-simple"), psname)->setData(QVariant(pg));
else if (pg == 1)
- menuScheme->addAction(IconManager::instance().loadIcon("page-doublesided"), psname)->setData(QVariant(pg));
+ buttonScheme->addAction(IconManager::instance().loadIcon("page-doublesided"), psname)->setData(QVariant(pg));
else if (pg == 2)
- menuScheme->addAction(IconManager::instance().loadIcon("page-3fold"), psname)->setData(QVariant(pg));
+ buttonScheme->addAction(IconManager::instance().loadIcon("page-3fold"), psname)->setData(QVariant(pg));
else if (pg == 3)
- menuScheme->addAction(IconManager::instance().loadIcon("page-4fold"), psname)->setData(QVariant(pg));
+ buttonScheme->addAction(IconManager::instance().loadIcon("page-4fold"), psname)->setData(QVariant(pg));
else
- menuScheme->addAction(IconManager::instance().loadIcon("page-simple"), psname)->setData(QVariant(pg));
+ buttonScheme->addAction(IconManager::instance().loadIcon("page-simple"), psname)->setData(QVariant(pg));
}
-
- connect(menuScheme, &QMenu::triggered, this, &PageLayouts::changeScheme);
}
void PageLayouts::reloadFirstPage(int scheme)
{
- disconnect(menuFirstPage, &QMenu::triggered, this, &PageLayouts::changeFirstPage);
-
- menuFirstPage->clear();
+ buttonFirstPage->clear();
// We have to add the other cases if want to support them again
// CommonStrings::pageLocLeft
@@ -150,14 +140,13 @@ void PageLayouts::reloadFirstPage(int scheme)
QString psname = m_pageSets[scheme].pageNames[pg];
if (psname == CommonStrings::pageLocLeft)
- menuFirstPage->addAction(IconManager::instance().loadIcon("page-first-left"), psname)->setData(QVariant(pg));
+ buttonFirstPage->addAction(IconManager::instance().loadIcon("page-first-left"), psname)->setData(QVariant(pg));
else if (psname == CommonStrings::pageLocRight)
- menuFirstPage->addAction(IconManager::instance().loadIcon("page-first-right"), psname)->setData(QVariant(pg));
+ buttonFirstPage->addAction(IconManager::instance().loadIcon("page-first-right"), psname)->setData(QVariant(pg));
else
- menuFirstPage->addAction(IconManager::instance().loadIcon("page-first-left"), psname)->setData(QVariant(pg));
+ buttonFirstPage->addAction(IconManager::instance().loadIcon("page-first-left"), psname)->setData(QVariant(pg));
}
- connect(menuFirstPage, &QMenu::triggered, this, &PageLayouts::changeFirstPage);
}
void PageLayouts::toggleLabelVisibility(bool visibility)
@@ -179,22 +168,35 @@ void PageLayouts::languageChange()
labelScheme->setText( tr( "Scheme" ) );
labelPages->setText( tr( "First Page" ) );
+ QSignalBlocker sigButtonScheme(buttonScheme);
+ buttonScheme->setCurrentIndex(buttonScheme->currentIndex());
buttonScheme->setToolTip( tr( "Number of pages to show side-by-side on the canvas. Often used for allowing items to be placed across page spreads." ) );
+
+ QSignalBlocker sigFirstPage(buttonFirstPage);
+ buttonFirstPage->setCurrentIndex(buttonFirstPage->currentIndex());
buttonFirstPage->setToolTip( tr( "Location on the canvas where the first page of the document is placed" ) );
}
-void PageLayouts::changeScheme(QAction *action)
+void PageLayouts::changeScheme(int index)
{
- buttonScheme->setIcon(action->icon());
+ QAction * action = buttonScheme->menu()->actions().at(qBound(0, index, buttonScheme->menu()->actions().size()));
+
+ if (!action)
+ return;
+
int ic = action->data().toInt();
reloadFirstPage(ic);
labelPages->setVisible( ic > 0 );
emit schemeChanged(ic);
}
-void PageLayouts::changeFirstPage(QAction *action)
+void PageLayouts::changeFirstPage(int index)
{
- buttonFirstPage->setIcon(action->icon());
+ QAction * action = buttonFirstPage->menu()->actions().at(qBound(0, index, buttonFirstPage->menu()->actions().size()));
+
+ if (!action)
+ return;
+
m_firstPage = action->data().toInt();
emit firstPageChanged(m_firstPage);
}
diff --git a/scribus/ui/widgets/pagelayout.h b/scribus/ui/widgets/pagelayout.h
index d404ba4d8..473789ba9 100644
--- a/scribus/ui/widgets/pagelayout.h
+++ b/scribus/ui/widgets/pagelayout.h
@@ -16,6 +16,7 @@ class QHBoxLayout;
class QLabel;
class QMenu;
class QToolButton;
+class DropdownButton;
#include "scribusapi.h"
#include "scribusstructs.h"
@@ -57,10 +58,8 @@ private:
FormWidget* labelScheme { nullptr };
FormWidget* labelPages { nullptr };
- QToolButton* buttonScheme { nullptr };
- QToolButton* buttonFirstPage { nullptr };
- QMenu* menuScheme { nullptr };
- QMenu* menuFirstPage { nullptr };
+ DropdownButton* buttonScheme { nullptr };
+ DropdownButton* buttonFirstPage { nullptr };
QHBoxLayout* layoutGroupLayout { nullptr };
void reloadScheme();
@@ -68,8 +67,8 @@ private:
protected slots:
void languageChange();
- void changeScheme(QAction* action);
- void changeFirstPage(QAction* action);
+ void changeScheme(int index);
+ void changeFirstPage(int index);
};
|
|
|
I noticed this issue on macOS where the OS is not in dark mode but the app is |
|
|
Let us know if this patch should be applied or wait... |
|
|
Does it happen before you applied the patch too? Could be another issue, maybe this patch solves it? https://bugs.scribus.net/view.php?id=17571 |
|
|
I cannot get that patch to apply easily, and cannot find the tool button class. Too many bugs with too many patches that depend on each other. My tree is reset to SVN as of now to clean out the old mess. I could apply the patch for this bug if it fixes determined issues. If it requires other classes, please include those. Also, ToolButton is very close to QToolButton etc. I'd recommend ScToolButton or something similar. |
| Date Modified | Username | Field | Change |
|---|---|---|---|
| 2025-12-07 20:47 | cbradney | New Issue | |
| 2025-12-07 20:47 | cbradney | Status | new => assigned |
| 2025-12-07 20:47 | cbradney | Assigned To | => nitramr |
| 2025-12-07 20:47 | cbradney | Issue generated from: 0017704 | |
| 2025-12-07 20:48 | cbradney | Note Added: 0053353 | |
| 2025-12-07 20:48 | cbradney | File Added: colorfix.patch | |
| 2025-12-07 20:49 | cbradney | Note Added: 0053354 | |
| 2025-12-07 20:49 | cbradney | File Added: Screenshot 2025-12-07 at 21.43.21 (2).png | |
| 2025-12-07 21:03 | cbradney | Note Added: 0053355 | |
| 2025-12-07 21:12 | nitramr | Note Added: 0053356 | |
| 2025-12-07 21:36 | cbradney | Note Added: 0053357 |
