View Issue Details

IDProjectCategoryView StatusLast Update
0012525ScribusGraphics / Image Framespublic2018-04-30 13:36
ReporterKunda Assigned To
PrioritynormalSeverityminorReproducibilityalways
Status confirmedResolutionopen
PlatformMacOSOSXOS Version10.8.5
Product Version1.5.0svn
Target VersionFixed in Version
Summary0012525: GraphicsMagick won't export SLA because of SVG, "Failed to load an image mask"
DescriptionWhen trying to export to PDF that has a specific SVG in it, I get the error 'Failed to load an image mask'
The 'Collect for output' compressed directory is attached along with a screenshot of the error
Steps To Reproduce1) Open a New SLA
2) Create an Image frame
3) Import easterlillies-frame(publicdomainvectors).svg
4) Try to export to PDF

or
1) unzip attached compressed archive
2) open SLA
3) Try to export to PDF
Additional Information1.5svn r19342
TagsGraphicsMagick, upstream
PatchNo

Relationships

related to 0011994 closedcbradney The GraphicsMagick plug-in doesn't recognise all supported formats, even though they can be imported
child of 0002931 acknowledged Metabug: SVG

Activities

Kunda

2014-07-15 03:58

manager

image-mask-svg-issue.zip (81,698 bytes)

Kunda

2014-07-15 03:58

manager

Kunda

2014-07-16 16:25

manager   ~0032782

Last edited: 2015-12-13 14:40

View 3 revisions

From MrB on IRC:

>MrB:
else
{
bool gotAlpha = false;
bool pdfVer14 = (Options.Version >= PDFOptions::PDFVersion_14) || (Options.Version == PDFOptions::PDFVersion_X4);
gotAlpha = img2.getAlpha(fn, c->pixm.imgInfo.actualPageNumber, im2, true, pdfVer14, afl, img.width(), img.height());
if (!gotAlpha)
{
PDF_Error_MaskLoadFailure(fn);
return false;
}
alphaM = !im2.isEmpty();
}

>Kunda: I'll take a stab at it: so it's failing because it doesn't(?) have an alpha layer and it's trying to be exported in the wrong pdf format version?
>MrB: yeah i guess so.. but i wonder why thats a requirement. a valid svg could also just be a solid rectangle

FirasH

2014-07-16 16:32

developer   ~0032784

Same here with 1.5.0.svn (19347) on openSUSE.

JLuc

2014-07-24 22:06

developer   ~0032969

I confirm the issue on ubuntu.

Strange is that the preflight checker does issue a warning : "item has got some transparency" !!! (translated from french).

scribus knows it has a transparency in the preflight checker
but lands in that (!gotAlpha) part a few seconds later when creating the PDF...

I also had a crash a few seconds later the first time i tried, but cannot reproduce the crash.

JLuc

2014-07-24 22:14

developer   ~0032970

PS : following cited code excerpt if condition, i did test with export to PDF version 1.4

Kunda

2014-07-24 23:10

manager   ~0032973

jghali says he can't reproduce it on windows (not sure what win version he is using)

Kunda

2014-07-26 13:05

manager   ~0033022

The non-ideal workaround was changing the SVG in to a PNG :(
The issue still remains except on windows per jghali)

jghali

2014-07-26 16:00

administrator   ~0033030

I've compiled latest trunk version in an OpenSuse 13.1 VM and... I cannot reproduce the issue either...

jghali

2014-07-26 17:59

administrator   ~0033031

Same in Ubuntu 14.04, I cannot reproduce the issue.

jghali

2014-07-26 18:10

administrator   ~0033032

I wonder if the use of GraphicksMagick may be involved in this issue...

Kunda

2014-07-27 06:27

manager   ~0033039

Good thinking. I will figure out how to tweak the build formula to not build with GraphicksMagick and report back soon

Kunda

2014-08-02 17:50

manager   ~0033154

jghali, Confirmed this is a GraphicsMagick issue. I compiled r19395 without GM support (v1.3.19) and was able to export the SVG to pdf. How do we proceed ?

Kunda

2015-12-13 14:48

manager   ~0037914

Last edited: 2015-12-13 14:49

View 2 revisions

Can still reproduce on
OSX 10.10.5 1.5.1svn r20620
Graphicsmagick 1.3.23

CLI output:
embed list: ""
subset list: ""
outline list: ""
Failed to read image "/Users/blah/Downloads/FFbrowser/image-mask-svg-issue/images/easterlillies-frame(publicdomainvectors).svg"


Kunda

2015-12-16 13:19

manager   ~0037926

How do i simulate this in GM without Scribus?

Kunda

2016-01-21 13:06

manager   ~0038319

Last edited: 2016-01-21 13:19

View 3 revisions

Running in graphicsmagick
Test:~ blah$ gm identify /Users/blah/Downloads/image-mask-svg-issue/images/easterlillies-frame\(publicdomainvectors\).svg
gm identify: Request did not return an image.


Note: I can successfully run 'gm convert' and convert the .svg to a .pdf with no problem. Example:
Test:~ blah$ gm convert /Users/blah/Downloads/image-mask-svg-issue/images/easterlillies-frame-publicdomainvectors.svg test.pdf


Running in imagemagick
Test:~ blah$ identify /Users/blah/Downloads/image-mask-svg-issue/images/easterlillies-frame\(publicdomainvectors\).svg
sh: line 1: 23898 Trace/BPT trap: 5       "inkscape" "/var/tmp/magick-23896OgCaXiEAwfeo" --export-png="/var/tmp/magick-23896AwjhfrNrJPRE" --export-dpi="90_90" --export-background="rgb(100%_100%_100%)" --export-background-opacity="1" > "/var/tmp/magick-23896agkS6WzO9o4g" 2>&1
/Users/sphenoid/Downloads/image-mask-svg-issue/images/easterlillies-frame(publicdomainvectors).svg SVG 1003x1165 1003x1165+0+0 16-bit sRGB 187KB 0.000u 0:00.000


urzds

2017-03-16 09:43

reporter   ~0043611

I ran into the same issue with imagemagick 8:6.8.9.9-7ubuntu5.6 (Ubuntu 16.04 / KDE neon).

urzds

2017-03-16 10:38

reporter   ~0043612

The same issue occurs, if I additionally install graphicsmagick 1.3.23-1build1. I am using scribus-ng 1.5.2-0ubuntu16.04.0~ppa0.

GraphicsMagick's `gm identify` fails for all SVG images used in my SLA file with "Request did not return an image.". ImageMagick's `identify` succeeds for all SVG images, telling me reasonable dimensions for them.

Please note that I chose to embed all images into the SLA.

urzds

2017-03-16 10:41

reporter   ~0043613

scribus-trunk 1.5.3svn~r21826~20170315~ppa66~ubuntu16.04.1 does not show this issue.
